SIZES
PRO, PRO XL, PRO XXL
MODEL CODE
G47201U
FRAME
GT Speed Series MK7 Elite Race Design, 6061-T6 AL, Alloy Formed and Butted Speed Metal Tubes, AL CNC/Forged Quick Change Disc Dropout SyStem, BB86, Taper 1-1/8" to 1-1/2" Integrated H/T
FORK
GT BMX Pro Race, 100% Cr-Mo 1 1/8" Steerer, Tapered Legs, 3/8" Dropouts
CHAIN
KMC Z1 Narrow, 3/32"
CRANK
GT Forged Alloy 2pc., 175mm Arms, 24mm Hollow/ Cr-Mo Spindle, 44T AL CNC Chain Ring, Alloy Chain Ring Bolts
BOTTOM BRACKET
Sealed BB86
PEDALS
GT Low Profile FS Platform Design
COG SET
16T Cog
RIMS
Alloy Double Wall, 36h
TIRES
Kenda Kompact Pro Race 20 x 1.75"
FRONT HUB
GT Speed Series, Alloy CNC Body, Sealed Bearings, 28h, 3/8" Female Allen Bolts
REAR HUB
GT Speed Series Disc Cassette, Alloy CNC body, 4 Sealed Bearings, 6 Pawl 72point Alloy Shimano Cassette, 36h, 3/8" Female Allen Bolts w/ Alloy Washers
SPOKES
Stainless Steel, 14g
BRAKES
Promax Hydro Disc Rear, 140mm Rotor (Rear Only)
FRONT BRAKE
Promax Hydro Disc Rear, 140mm Rotor (Rear Only)
REAR BRAKE
Promax Hydro Disc Rear, 140mm Rotor (Rear Only)
BRAKE LEVERS
Alloy, 2 Finger
HANDLEBAR
GT Speed Cr-Mo 8.375"H x 29"W, 8° Sweep, 4° Up, Taper Cross Bar
STEM
Promax Impact Top Load, 53mm
GRIPS
GT Statement Double Lock-on Grips
HEADSET
1-1/8"-1.5" Taper Integrated Design, 45X45 Degree Sealed Bearings
SADDLE
BOX Echelon
SEAT POST
Integrated
